SKU: UELFL215D1-NTN
NTN UELFL215D1 Metric Two Bolt Cast Iron Oval Housing with 75mm Bore Eccentric Collar Insert - Allow 2-3 Days
NTN UELFL215D1 Metric Two Bolt Cast Iron Oval Housing with 75mm Bore Eccentric Collar Insert - Allow 2-3 Days
Out of stock
Share this product
Description
Description
UELFL200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 75mm
- Style:
- UELFL
- Bolt Hole Centres:
- 225mm
Technical
Technical
| Shaft diameter | 75mm |
|---|---|
| H | 275mm |
| J | 225mm |
| A<sub>2</sub> | 34mm |
| A<sub>1</sub> | 22mm |
| A | 56mm |
| N | 23mm |
| L | 165mm |
| A<sub>0</sub> | 88.7mm |
| B<sub>1</sub> | 92mm |
| S | 37.3mm |
| F min. | 97mm |
| Fixing bolt | M20 |
| Mass | 6.3 kg |
