• Dunlop FBL-16CG Left Hand Metric Steel / Bronze Lined Maintenance Required Plain Female Rod End M16x1.5 Thread - Allow 7-10 Days
  • Dunlop FBL-16CG Left Hand Metric Steel / Bronze Lined Maintenance Required Plain Female Rod End M16x1.5 Thread - Allow 7-10 Days
  • Dunlop FBL-16CG Left Hand Metric Steel / Bronze Lined Maintenance Required Plain Female Rod End M16x1.5 Thread - Allow 7-10 Days
  • Dunlop FBL-16CG Left Hand Metric Steel / Bronze Lined Maintenance Required Plain Female Rod End M16x1.5 Thread - Allow 7-10 Days
1 4

SKU: FBL-M16CG-DUN

Dunlop FBL-16CG Left Hand Metric Steel / Bronze Lined Maintenance Required Plain Female Rod End M16x1.5 Thread - Allow 7-10 Days

Dunlop FBL-16CG Left Hand Metric Steel / Bronze Lined Maintenance Required Plain Female Rod End M16x1.5 Thread - Allow 7-10 Days
CHF 20.00 ex VAT
CHF 20.00 ex VAT
Sale Sold out

In stock
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
FB Series Maintenance Required Female Rod Ends: The FB series are a standard range of maintenance required general purpose female rod ends suitable for medium heavy industrial/mechanical load applications requiring low friction and good wear resistance, available in both metric and imperial bore and thread sizes. Temperature range -34c to +149c
Benefits: Low friction, extended wear life
Brand / Quality:
Dunlop - High Quality
Thread Size:
M16x1.5
Thread M / F:
Female
Thread Direction:
Left Hand
Material:
Bronze Lined
Technical
Bore size 16mm
Thread M16x1.5
W 21mm
H 15mm
D 38mm
L1 64mm
L2 33mm
O 19.3mm
AF 22mm
Static load 0.3713 N
