• Timken 32222 Metric Taper Roller Bearing 110x200x56mm
1 1

SKU: 32222-TIM

Timken 32222 Metric Taper Roller Bearing 110x200x56mm

Timken 32222 Metric Taper Roller Bearing 110x200x56mm
CHF 594.00 ex VAT
CHF 594.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 475.10
20+ CHF 448.40
30+ CHF 443.07
40+ CHF 437.73
50+ CHF 432.39
75+ CHF 427.05
100+ CHF 400.36
200+ CHF 395.02
250+ CHF 389.69
500+ CHF 384.35
1000+ CHF 373.67
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer).
Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load
Brand / Quality:
Timken - High Quality
Inside Diameter:
110mm
Outside Diameter:
200mm
Width:
56mm
Technical
d 110mm
D 200mm
T 56mm
Dynamic load 402 kN
Static load 570 kN
Fatigue load limit Pu 61 kN
Reference speed 2400 rpm
Limiting speed 3200 rpm
Mass 7.1 kg
d1 151mm
B 53mm
C 46mm
r1r2 min 3mm
r3r4 min 2.5mm
a 46mm
da max 127mm
db min 122mm
Da min 170mm
Da max 188mm
Db min 190mm
Ca min 6mm
Cb min 10mm
ra max 2.5mm
rb max 2mm
e 0.43
Y 1.4
Y0 0.8
