• Timken 30210 Metric Taper Roller Bearing 50x90x21.75mm
1 1

SKU: 30210-TIM

Timken 30210 Metric Taper Roller Bearing 50x90x21.75mm

Timken 30210 Metric Taper Roller Bearing 50x90x21.75mm
CHF 56.00 ex VAT
CHF 56.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 44.64
20+ CHF 42.13
30+ CHF 41.63
40+ CHF 41.13
50+ CHF 40.62
75+ CHF 40.12
100+ CHF 37.61
200+ CHF 37.11
250+ CHF 36.61
500+ CHF 36.11
1000+ CHF 35.11
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer).
Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load
Brand / Quality:
Timken - High Quality
Inside Diameter:
50mm
Outside Diameter:
90mm
Width:
21.75mm
Technical
d 50mm
D 90mm
T 21.75mm
Dynamic load 76.5 kN
Static load 91.5 kN
Fatigue load limit Pu 10.4 kN
Reference speed 5600 rpm
Limiting speed 7500 rpm
Mass 0.54 kg
d1 67.9mm
B 20mm
C 17mm
r1r2 min 1.5mm
r3r4 min 1.5mm
a 19mm
da max 58mm
db min 57mm
Da min 79mm
Da max 83mm
Db min 85mm
Ca min 3mm
Cb min 4.5mm
ra max 1.5mm
rb max 1.5mm
e 0.43
Y 1.4
Y0 0.8
