SKU: WLK20-00-500-DURB
Durbal WLK20-00-500 Steel Spherical Plain Bearing 20x50x25mm
Durbal WLK20-00-500 Steel Spherical Plain Bearing 20x50x25mm
Out of stock
Share this product
Description
Description
DURBAL Heavy-Duty Spherical Bearings with Integral Self-Aligning Ball Bearing: These spherical bearings are made from hardened and super-finished steel. For high speeds, wide swivelling angles or rotating movements. These bearings have low bearing friction. Low maintenance due to long-term lubrication with food-grade approval. Covering discs on both sides to prevent the penetration of coarse dirt particles inside the bearing. Temperature range: -45 deg C to +120 deg C.
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 20mm
Technical
Technical
| d | 20mm |
|---|---|
| D | 50mm |
| B | 25mm |
| C | 18mm |
| d1 | 24.3mm |
| tilt angle α | 7 deg |
| weight | 0.25kg |
| rotational speed limit n max | 825 min-1 |
| Axial Factor Y | 2.46 Y0 |
| Axial Factor Y0 | 2.58 Y0 |
| basic load rating dyn C | 7.9 kN |
| basic load rating stat Co | 3.5 kN |
| radial clearance CN | 10-30 µm |
