• SKF TMHP30/350 Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in
1 1

SKU: TMHP30/350-SKF

SKF TMHP30/350 Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in

SKF TMHP30/350 Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in
CHF 8,151.00 ex VAT
CHF 8,151.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 6,523.28
19+ CHF 6,449.99
29+ CHF 6,376.69
39+ CHF 6,303.40
49+ CHF 6,230.10
74+ CHF 6,156.81
99+ CHF 6,083.51
199+ CHF 6,010.22
249+ CHF 5,936.92
499+ CHF 5,863.63
999+ CHF 5,790.33

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Hydraulically Assisted Heavy Duty Jaw Pullers TMHP Series: The SKF hydraulically-assisted pullers TMHP 15, TMHP 30 and TMHP 50 provide new combined forces of puller power and safety. They are self-centring pullers for the occasions when large forces are inevitable. Pantograph system for ultimate alignment of withdrawal forces and minimised risk of damaging shaft or bearing.
Benefits: Extreme forces applied with ease (self-centring, lifting handle, eye bolt, etc.)
Brand / Quality:
SKF - High Quality
Technical
Width of Grip 290-500mm (11.4-19.7 in.)
Effective Length of Arms 350mm (13.7 in.)
Claw Height 35mm (1.4 in.)
Stroke 50mm (2 in.)
Maximum Working Pressure Hydraulic Cylinder 80 Mpa (11 600 psi)
Maximum Withdrawal Force 300 kN (34 US ton)
