SKU: SYFL1.1/2TH-SKF
SKF SYFL1-1/2TH Composite Plummer Block with Food Grease Grub Screw Insert 1-1/2 inch
SKF SYFL1-1/2TH Composite Plummer Block with Food Grease Grub Screw Insert 1-1/2 inch
Out of stock
Description
Description
|
SKF Y-bearing Short Base Plummer Block Units for the Food Industry: Developed specifically for food and beverage applications. The housing of this unit is made of a chemical and corrosion resistant composite material which is designed to withstand frequent washdowns. The non-porous surface resists the accumulation of bacteria-forming food particles and the light-grey colour makes visual inspection easy. These units are lubricated with food-grade grease. Benefits: Designed for the food industry, lubricated with food-grade grease, optimised for handling shock loads and high vibration levels. |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 38.1mm = 1.5 (1-1/2) inch
- Style:
- SYFL
- Bolt Hole Centres:
- 88.9mm
Technical
Technical
| d | 1-1/2 inch |
|---|---|
| A | 48mm |
| A1 | 35mm |
| B | 49.2mm |
| H | 100.5mm |
| H1 | 49.2mm |
| J | 88.9mm |
| L | 120mm |
| G | M12 |
| G1 | 20mm |
| s1 | 30.2mm |
| Static load Cr | 19 kN |
| Dynamic load Cor | 24.7 kN |
| Fatigue load limit Pu | 0.8 kN |
| Limiting speed | 2800 rpm |
| A5 | 31.5mm |
| A6 | 33.5mm |
| Weight | 0.9 kg |
| Housing | SYFL508 |
| Insert | YAR208-108-2RF/HV |
| Compatible end cover closed | ECL208 |
| Compatible end cover open | ECL208-108B |
