SKU: SSM0500_160MM
50mm Diameter Silver Steel Round Bar - 160mm
50mm Diameter Silver Steel Round Bar - 160mm
Regular price
CHF 75.00
ex VAT
Regular price
Sale price
CHF 75.00
ex VAT
In stock
Price Break
2+
CHF 59.52
10+
CHF 56.18
20+
CHF 55.51
30+
CHF 54.84
40+
CHF 54.17
50+
CHF 53.50
60+
CHF 50.16
70+
CHF 49.49
80+
CHF 48.82
90+
CHF 48.15
100+
CHF 46.82
Quantity
Couldn't load pickup availability
Description
Description
Silver Steel: Silver steel is precision round bar stock conforming to BS1407. It is manufactured in a centreless grinding process and can be machined, reworked and hardened as required. Each length is supplied with protective coating solution applied to it to ensure its finish is maintained.
Benefits: Silver Steel can be machined, softened, re-hardened and tempered by heat treatment processes.
Tolerance guide: Bars of less than 25mm diameter or 1 inch: Tolerances are stated as maximum +/- 0.015mm on diameter.
Bars between 25mm to 50mm or 1 inch to 2 inch: Tolerances are stated as maximum +/- 0.025mm on diameter.
- Brand / Quality:
- Simply Silver Steel - High Quality
- Outside Diameter:
- 50mm
- Length:
- 160mm
Technical
Technical
| Diameter d | 50mm |
|---|---|
| Length Approx h | 325mm |
| Analysis Range (%) | Typical Analysis (%) |
| C. 95 / 1.25 | 1.13% |
| Si 0.40 max | 0.22% |
| Mn 0.25 / 0.45 | 0.37% |
| P 0.045 max | 0.014% |
| S 0.045 max | 0.018% |
| Cr 0.35 / 0.45 | 0.43% |
