SKU: RCK15-25x65

RCK1525x65 Shaft Clamping Element for Hubs of 25mm Bore Diameter

RCK1525x65 Shaft Clamping Element for Hubs of 25mm Bore Diameter
CHF 17.00 ex VAT
CHF 17.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 12.42
20+ CHF 12.28
30+ CHF 12.13
50+ CHF 11.98
75+ CHF 11.83
100+ CHF 11.09
200+ CHF 10.94
250+ CHF 10.80
500+ CHF 10.65
1000+ CHF 10.35

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
HEAD_RCK_15
Brand / Quality:
Cross & Morse - High Quality
Inside Diameter:
25mm
Outside Diameter:
65mm
Width:
39mm
Technical
d 25mm
D 65mm
L 39mm
L<sub>1</sub> 17mm
L<sub>2</sub> 22mm
L<sub>3</sub> 31mm
X 25mm
Torque Cap. M Nm 637
Axial Force F kN 51
Shaft Ps N/mm<sup>2</sup> 320
Hub Ph N/mm<sup>2</sup> 122
M8 M8
Clamping Screws Torque Nm 41
Kg 0.63
Min. Hub Dia. Assy. A 97
Min. Hub Dia. Assy. B 89
Min. Hub Dia. Assy. C 82
