SKU: NF.207.C3.MB

Major Brand NF207C3 Cylindrical Roller Bearing 35x72x17mm

Name: Major Brand NF207C3 Cylindrical Roller Bearing 35x72x17mm
Brand: Major Brand
SKU: NF.207.C3.MB
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

NF and MRJA Series Single Row Cylindrical Roller Bearings: The outer ring of this type has one integral flange / shoulder, the inner raceway has a two flanges / shoulders around which the cage and rollers are assembled. The outer raceway shoulder permits the ease of assembly and limits axial location to one direction.
Benefits: Axial location, ease of assembly and fitting

Brand / Quality:: Major Brand - High Quality
Inside Diameter:: 35mm
Outside Diameter:: 72mm
Width:: 17mm
Seals / Shields:: None
Clearance:: C3

Technical

d	35mm
D	72mm
B	17mm
Ew	61.8mm
Fw	43.8mm
r1	1.1mm
0.6mm	Dynamic Load
33500N	Static Load
31500N	Speed in Grease
9000rpm	Speed in Oil
11000rpm	da min
42mm	db min
40mm	db max
43mm	dc
46mm	Da max
65mm	Db min
67mm	Db max
64mm	ra max
1mm	ra1 max
0.6mm	Weight
0.295kg	N/A
