SKU: KMTA17-SKF
SKF KMTA17 Precision Locking Nut with Locking Pins M85x2mm
SKF KMTA17 Precision Locking Nut with Locking Pins M85x2mm
Out of stock
Share this product
Description
Description
|
SKF Precision KMTA Lock Nuts: Manufactured with standard ISO threads and a relieved external diameter primarily used for precision bearing installation. The inclusion of 3 locking pins mounted at 120 degrees around the perimeter and diagonally to the threads and allow for minor radial alignment adjustments. Benefits: Efficient, secure, inexpensive, removable and re-useable |
- Brand / Quality:
- SKF - High Quality
- Thread Size:
- M85x2
Technical
Technical
| G | M85x2 |
|---|---|
| d2 | 115mm |
| d3 | 102mm |
| d4 | 88mm |
| B | 32mm |
| J1 | 100mm |
| J2 | 17mm |
| N1 | 6.4mm |
| N2 | 8mm |
| Axial load capacity | 650 kN |
| Loosening torque | 660 Nm |
| Weight | 1.15 kg |
| Spanner | B110-115 |
| Grub Screw | M10 |
| Screw torque | 35 Nm |
| Name | KMTA17 |
