• igubal KCLM10 Left Hand Female Plastic Rod End 10mm Bore M10 Thread
1 1

SKU: KCLM-10

igubal KCLM10 Left Hand Female Plastic Rod End 10mm Bore M10 Thread

igubal KCLM10 Left Hand Female Plastic Rod End 10mm Bore M10 Thread
CHF 16.00 ex VAT
CHF 16.00 ex VAT
Sale Sold out

In stock

Price Break
4+ CHF 12.30
9+ CHF 11.61
19+ CHF 11.47
29+ CHF 11.34
39+ CHF 11.20
49+ CHF 11.06
59+ CHF 10.37
69+ CHF 10.23
79+ CHF 10.09
89+ CHF 9.95
99+ CHF 9.68

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KCLM_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
M10
Thread M / F:
Female
Thread Direction:
Left Hand
Inside Diameter:
10mm
Technical
d1 10mm
d2 30mm
d3 M10
W SW15
B 14
mmC 10.5mm
h1 43mm
l3 22mm
l4 58mm
Max pivot angle 35°
Max static tensile strength (short term) 3100 N
Max static tensile strength (long term) 1500 N
Max radial load (short term) 800 N
Max radial load (long term) 400 N
Max torque strength inner threading 3 Nm
Weight 12.8 g
