• igubal KBLI16 Left Hand Female Plastic Rod End 1 inch Bore 1-12 Thread - Allow 2-3 Days
1 1

SKU: KBLI-16

igubal KBLI16 Left Hand Female Plastic Rod End 1 inch Bore 1-12 Thread - Allow 2-3 Days

igubal KBLI16 Left Hand Female Plastic Rod End 1 inch Bore 1-12 Thread - Allow 2-3 Days
CHF 36.00 ex VAT
CHF 36.00 ex VAT
Sale Sold out

In stock

Price Break
4+ CHF 28.14
9+ CHF 26.56
19+ CHF 26.24
29+ CHF 25.93
39+ CHF 25.61
49+ CHF 25.29
59+ CHF 23.71
69+ CHF 23.40
79+ CHF 23.08
89+ CHF 22.76
99+ CHF 22.13

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
KBLI_DESC
Brand / Quality:
Igus - High Quality
Thread Size:
1-12
Thread M / F:
Female
Thread Direction:
Left Hand
Inside Diameter:
25.4mm = 1 inch
Technical
d1 1 inch
d2 2.75 inch
d3 1-12 inch
d4 1.625 inch
C1 1 inch
B 1.375 inch
h1 4.125 inch
l3 2.125 inch
l4 5.5 inch
W 1.5 inch
Max pivot angle 20°
Max static tensile strength (short term) 6000 N
Max static tensile strength (long term) 3000 N
Max radial load (short term) 2600 N
Max radial load (long term) 1300 N
Min thread depth 1.488 inch
Max torque outside thread 46 Nm
Max torque through ball 85 Nm
Weight 197.5 g
