• Major Brand K35x40x27TN Needle Roller Cage Assembly 35x40x27mm
1 1

SKU: K35x40x27TN-MB

Major Brand K35x40x27TN Needle Roller Cage Assembly 35x40x27mm

Major Brand K35x40x27TN Needle Roller Cage Assembly 35x40x27mm
CHF 16.00 ex VAT
CHF 16.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 12.33
19+ CHF 11.64
29+ CHF 11.50
39+ CHF 11.36
49+ CHF 11.23
74+ CHF 11.09
99+ CHF 10.39
199+ CHF 10.26
249+ CHF 10.12
499+ CHF 9.98
999+ CHF 9.70

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Needle Roller Cage Assemblies: A ready to mount, self contained bearing component, they enable bearing arrangements with a high load carrying capacity and stiffness yet only requiring a minimal amount of radial space if the shaft and housing serve as raceways. Generally made with steel cages with no specific maximum temperature or when suffixed with TN a glass fibre reinforced polyamide cage material having a maximum operating temperature 120 deg C
Benefits: Low cost bearing solution, minimal radial space requirements, high running accuracy.
Brand / Quality:
Major Brand - High Quality
Inside Diameter:
35mm
Outside Diameter:
40mm
Width:
27mm
Technical
Fw 35mm
Ew 40mm
U 27mm
Dynamic load 23800 N
Static load 49000 N
Fatigue load limit Pu 6000 N
Speed in grease 8000 rpm
Speed in oil 12000 rpm
Weight 39 g
