SKU: BS2-2217-2CS/VT143-SKF

SKF BS222172CSVT143 Sealed Spherical Roller Bearing with Cylindrical Bore 85x150x44mm

Name: SKF BS222172CSVT143 Sealed Spherical Roller Bearing with Cylindrical Bore 85x150x44mm
Brand: Simply Bearings Ltd - Ball Bearings, Oil Seals, O-rings, V-Belts, SKF
SKU: BS2-2217-2CS/VT143-SKF
Price: 252.00 CHF
Availability: InStock

CHF 252.00 ex VAT

Sale Sold out

Equivalent to: BS222172RS/VT143

In stock

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: SKF - High Quality
Inside Diameter:: 85mm
Outside Diameter:: 150mm
Width:: 44mm
Seals / Shields:: Rubber Sealed
Clearance:: * Standard

Technical

---	Dimensions
d	85mm
D	150mm
B	44mm
D1	138mm
d2	98mm
r1r2 min	2mm
b	5.5mm
K	3mm
da min	96mm
da max	98mm
Da max	139mm
ra max	2mm
---	Speeds, Loads and Weights
Dynamic load C	285 kN
Static load Co	325 kN
Fatigue load limit Pu	34.5 kN
Limiting speed	1100 rpm
Weight	3 kg
---	Factors
Calculation factor e	0.22
Calculation factor Y1	3
Calculation factor Y2	4.6
Calculation factor Y0	2.8
