• NSK 7912A5TRV1VSUMP3 Super Precision Sealed Angular Contact Spindle Bearing 60x85x13mm
1 1

SKU: 7912A5TRV1VSUMP3-NSK

NSK 7912A5TRV1VSUMP3 Super Precision Sealed Angular Contact Spindle Bearing 60x85x13mm

NSK 7912A5TRV1VSUMP3 Super Precision Sealed Angular Contact Spindle Bearing 60x85x13mm
CHF 299.00 ex VAT
CHF 299.00 ex VAT
Sale Sold out

In stock

Price Break
3+ CHF 234.42
5+ CHF 221.25
10+ CHF 218.62
25+ CHF 215.98
49+ CHF 213.35
74+ CHF 210.71
99+ CHF 197.54
199+ CHF 194.91
249+ CHF 192.28
499+ CHF 189.64
999+ CHF 184.37

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
FOIYY32A5T
Brand / Quality:
NSK - High Quality
Inside Diameter:
60mm
Outside Diameter:
85mm
Width:
13mm
Seals / Shields:
Rubber Sealed
Style:
Single Universal Matchable Bearing
Contact Angle:
25 Degree contact angle
Bearing Preload:
Medium preload
Technical
--- Bearing dimensions
d 60mm
D 85mm
B 13mm
r<sub>min</sub> 1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 19.2Kn
C<sub>or</sub> 17.7kN
Axial load Kn 13 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 23.4mm
Max speed in grease 13800 rpm
Max speed in oil 20700 rpm
--- Fitting dimensions
d<sub>a min</sub> 66mm
D<sub>a max</sub> 79mm
D<sub>b max</sub> 80mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.5mm
Weight 0.198kg
