• NSK 7910A5TRV1VDUMP3 Super Precision Sealed Angular Contact Spindle Bearing 50x72x12mm (Set of 2)
1 1

SKU: 7910A5TRV1VDUMP3-NSK

NSK 7910A5TRV1VDUMP3 Super Precision Sealed Angular Contact Spindle Bearing 50x72x12mm (Set of 2)

NSK 7910A5TRV1VDUMP3 Super Precision Sealed Angular Contact Spindle Bearing 50x72x12mm (Set of 2)
CHF 449.00 ex VAT
CHF 449.00 ex VAT
Sale Sold out

In stock

Price Break
3+ CHF 358.97
5+ CHF 338.80
10+ CHF 334.77
25+ CHF 330.74
49+ CHF 326.70
74+ CHF 322.67
99+ CHF 302.50
199+ CHF 298.47
249+ CHF 294.44
499+ CHF 290.40
999+ CHF 282.34

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
5ZG1TM6ZIA
Brand / Quality:
NSK - High Quality
Inside Diameter:
50mm
Outside Diameter:
72mm
Width:
12mm
Seals / Shields:
Rubber Sealed
Style:
Universal Matched Pair of Bearings
Contact Angle:
25 Degree contact angle
Bearing Preload:
Medium preload
Technical
--- Bearing dimensions
d 50mm
D 72mm
B 12mm
r<sub>min</sub> 0.6mm
r1<sub>min</sub> 0.3mm
--- Loads angles and speeds
C<sub>r</sub> 16.7Kn
C<sub>or</sub> 14.2kN
Axial load Kn 11 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 20.2mm
Max speed in grease 16400 rpm
Max speed in oil 24600 rpm
--- Fitting dimensions
d<sub>a min</sub> 55mm
D<sub>a max</sub> 67mm
D<sub>b max</sub> 69.5mm
r<sub>a max</sub> 0.6mm
r<sub>b max</sub> 0.3mm
Weight 0.264kg
