• NSK 7214CSN24TRDUELP3 Super Precision Angular Contact Spindle Bearing 70x125x24mm (Set of 2)
1 1

SKU: 7214CSN24TRDUELP3-NSK

NSK 7214CSN24TRDUELP3 Super Precision Angular Contact Spindle Bearing 70x125x24mm (Set of 2)

NSK 7214CSN24TRDUELP3 Super Precision Angular Contact Spindle Bearing 70x125x24mm (Set of 2)
CHF 1,856.00 ex VAT
CHF 1,856.00 ex VAT
Sale Sold out

In stock

Price Break
3+ CHF 1,485.26
5+ CHF 1,401.82
10+ CHF 1,385.13
25+ CHF 1,368.44
49+ CHF 1,351.75
74+ CHF 1,335.07
99+ CHF 1,251.62
199+ CHF 1,234.94
249+ CHF 1,218.25
499+ CHF 1,201.56
999+ CHF 1,168.18

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
5ZG1TM6ZIA
Brand / Quality:
NSK - High Quality
Inside Diameter:
70mm
Outside Diameter:
125mm
Width:
24mm
Seals / Shields:
None
Style:
Universal Matched Pair of Bearings
Contact Angle:
15 Degree contact angle
Bearing Preload:
Extra light preload
Technical
--- Bearing dimensions
d 70mm
D 125mm
B 24mm
r<sub>min</sub> 1.5mm
r1<sub>min</sub> 1mm
--- Loads angles and speeds
C<sub>r</sub> -83.5Kn
C<sub>or</sub> -64.5kN
Axial load Kn 51.3 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 14.6
Effective diameter 25.1mm
Max speed in grease 15400 rpm
Max speed in oil 23400 rpm
--- Fitting dimensions
d<sub>a min</sub> 79mm
D<sub>a max</sub> 116mm
D<sub>b max</sub> 119mm
r<sub>a max</sub> 1.5mm
r<sub>b max</sub> 0.8mm
Weight 1.796kg
