• NSK 7038A5TRDUHP3 Super Precision Angular Contact Spindle Bearing 190x290x46mm (Set of 2)
1 1

SKU: 7038A5TRDUHP3-NSK

NSK 7038A5TRDUHP3 Super Precision Angular Contact Spindle Bearing 190x290x46mm (Set of 2)

NSK 7038A5TRDUHP3 Super Precision Angular Contact Spindle Bearing 190x290x46mm (Set of 2)
CHF 6,201.00 ex VAT
CHF 6,201.00 ex VAT
Sale Sold out

In stock

Price Break
3+ CHF 4,962.94
5+ CHF 4,684.13
10+ CHF 4,628.36
25+ CHF 4,572.60
49+ CHF 4,516.84
74+ CHF 4,461.07
99+ CHF 4,182.26
199+ CHF 4,126.49
249+ CHF 4,070.73
499+ CHF 4,014.96
999+ CHF 3,903.44

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
5ZG1TM6ZIA
Brand / Quality:
NSK - High Quality
Inside Diameter:
190mm
Outside Diameter:
290mm
Width:
46mm
Seals / Shields:
None
Style:
Universal Matched Pair of Bearings
Contact Angle:
25 Degree contact angle
Bearing Preload:
Heavy preload
Technical
--- Bearing dimensions
d 190mm
D 290mm
B 46mm
r<sub>min</sub> 2.1mm
r1<sub>min</sub> 1.1mm
--- Loads angles and speeds
C<sub>r</sub> 245Kn
C<sub>or</sub> 291kN
Axial load Kn 222 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 79mm
Max speed in grease 3800 rpm
Max speed in oil 5900 rpm
--- Fitting dimensions
d<sub>a min</sub> 202mm
D<sub>a max</sub> 278mm
D<sub>b max</sub> 283mm
r<sub>a max</sub> 2mm
r<sub>b max</sub> 1mm
Weight 22.4kg
