• NSK 7026A5TRDUDMP3 Super Precision Angular Contact Spindle Bearing 130x200x33mm (Set of 3)
1 1

SKU: 7026A5TRDUDMP3-NSK

NSK 7026A5TRDUDMP3 Super Precision Angular Contact Spindle Bearing 130x200x33mm (Set of 3)

NSK 7026A5TRDUDMP3 Super Precision Angular Contact Spindle Bearing 130x200x33mm (Set of 3)
CHF 2,449.00 ex VAT
CHF 2,449.00 ex VAT
Sale Sold out

In stock

Price Break
3+ CHF 1,921.52
5+ CHF 1,813.57
10+ CHF 1,791.98
25+ CHF 1,770.39
49+ CHF 1,748.80
74+ CHF 1,727.21
99+ CHF 1,619.26
199+ CHF 1,597.67
249+ CHF 1,576.08
499+ CHF 1,554.49
999+ CHF 1,511.31

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
BDM8P7Y56R
Brand / Quality:
NSK - High Quality
Inside Diameter:
130mm
Outside Diameter:
200mm
Width:
33mm
Seals / Shields:
None
Style:
Universal Matched Triple Bearing Set
Contact Angle:
25 Degree contact angle
Bearing Preload:
Medium preload
Technical
--- Bearing dimensions
d 130mm
D 200mm
B 33mm
r<sub>min</sub> 2mm
r1<sub>min</sub> 1mm
--- Loads angles and speeds
C<sub>r</sub> 128Kn
C<sub>or</sub> 130kN
Axial load Kn 99.5 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 55mm
Max speed in grease 6100 rpm
Max speed in oil 9100 rpm
--- Fitting dimensions
d<sub>a min</sub> 140mm
D<sub>a max</sub> 190mm
D<sub>b max</sub> 194mm
r<sub>a max</sub> 2mm
r<sub>b max</sub> 1mm
Weight 10.98kg
