• NSK 7008A5TRDULP3 Super Precision Angular Contact Spindle Bearing 40x68x15mm (Set of 2)
1 1

SKU: 7008A5TRDULP3-NSK

NSK 7008A5TRDULP3 Super Precision Angular Contact Spindle Bearing 40x68x15mm (Set of 2)

NSK 7008A5TRDULP3 Super Precision Angular Contact Spindle Bearing 40x68x15mm (Set of 2)
CHF 327.00 ex VAT
CHF 327.00 ex VAT
Sale Sold out

In stock

Price Break
3+ CHF 261.22
5+ CHF 246.55
10+ CHF 243.61
25+ CHF 240.68
49+ CHF 237.74
74+ CHF 234.81
99+ CHF 220.13
199+ CHF 217.20
249+ CHF 214.26
499+ CHF 211.33
999+ CHF 205.46

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
5ZG1TM6ZIA
Brand / Quality:
NSK - High Quality
Inside Diameter:
40mm
Outside Diameter:
68mm
Width:
15mm
Seals / Shields:
None
Style:
Universal Matched Pair of Bearings
Contact Angle:
25 Degree contact angle
Bearing Preload:
Light preload
Technical
--- Bearing dimensions
d 40mm
D 68mm
B 15mm
r<sub>min</sub> 1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 20.5Kn
C<sub>or</sub> 15.1kN
Axial load Kn 12 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 20.1mm
Max speed in grease 18600 rpm
Max speed in oil 27800 rpm
--- Fitting dimensions
d<sub>a min</sub> 46mm
D<sub>a max</sub> 62mm
D<sub>b max</sub> 63mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.5mm
Weight 0.376kg
