• Timken 30222 Metric Taper Roller Bearing 110x200x41mm
1 1

SKU: 30222-TIM

Timken 30222 Metric Taper Roller Bearing 110x200x41mm

Timken 30222 Metric Taper Roller Bearing 110x200x41mm
CHF 433.00 ex VAT
CHF 433.00 ex VAT
Sale Sold out

In stock

Price Break
10+ CHF 345.80
20+ CHF 326.37
30+ CHF 322.49
40+ CHF 318.60
50+ CHF 314.72
75+ CHF 310.83
100+ CHF 291.41
200+ CHF 287.52
250+ CHF 283.63
500+ CHF 279.75
1000+ CHF 271.98

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
METRIC1_TRDESC
Brand / Quality:
Timken - High Quality
Inside Diameter:
110mm
Outside Diameter:
200mm
Width:
41mm
Technical
d 110mm
D 200mm
T 41mm
Dynamic load 308 kN
Static load 405 kN
Fatigue load limit Pu 45 kN
Reference speed 2400 rpm
Limiting speed 3200 rpm
Mass 5.1 kg
d1 148mm
B 38mm
C 32mm
r1r2 min 3mm
r3r4 min 2.5mm
a 39mm
da max 129mm
db min 122mm
Da min 174mm
Da max 188mm
Db min 187mm
Ca min 6mm
Cb min 9mm
ra max 2.5mm
rb max 2mm
e 0.43
Y 1.4
Y0 0.8
