FAG 23220E1AMC3 X-life Spherical Roller Bearing with Cylindrical Bore 100x180x60.3mm
FAG 23220E1AMC3 X-life Spherical Roller Bearing with Cylindrical Bore 100x180x60.3mm
Regular price
CHF 489.00
ex VAT
Regular price
Sale price
CHF 489.00
ex VAT
In stock
Price Break
3+
CHF 390.75
4+
CHF 368.79
9+
CHF 364.40
19+
CHF 360.01
29+
CHF 355.62
39+
CHF 351.23
49+
CHF 329.28
59+
CHF 324.89
249+
CHF 320.50
499+
CHF 316.11
999+
CHF 307.33
Quantity
Couldn't load pickup availability
Description
Description
|
Spherical Roller Bearings: These bearings have two rows of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway, they are inclined at an angle to the bearings axis. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants. Benefits: High radial and axial loads, misalignment, taper and parallel bore options |
- Brand / Quality:
- FAG - High Quality
- Inside Diameter:
- 100mm
- Outside Diameter:
- 180mm
- Width:
- 60.3mm
- Seals / Shields:
- None
- Clearance:
- C3
Technical
Technical
| --- | Dimensions |
|---|---|
| d | 100mm |
| D | 180mm |
| B | 60.3mm |
| r min. | 2.1mm |
| D1 | 156.7mm |
| ds | 4.8mm |
| ns | 9.5mm |
| da min. | 112mm |
| Da max. | 168mm |
| ra max. | 2.1mm |
| --- | Loads, Speeds and Weights |
| Fatigue limit load | 60000 N |
| Limiting speed | 3600 rpm |
| Reference speed | 2410 rpm |
| Dynamic Load Rating | 550000 N |
| Static Load Rating | 660000 N |
| Weight | 6.45kg |
| --- | Factors |
| e | 0.31 |
| Y1 | 2.15 |
| Y2 | 3.2 |
| Y0 | 2.1 |
