SKU: 08B-1-SYNO-25FT-RENOLD
Renold SYNO 08B-1 BS Simplex Roller Chain 1/2mm Pitch - 25 Feet Length Allow 2-3 Days
Renold SYNO 08B-1 BS Simplex Roller Chain 1/2mm Pitch - 25 Feet Length Allow 2-3 Days
Equivalent to: SNX08B-1
Out of stock
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Simplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 12.7mm = 0.5 (1/2) inch
Technical
Technical
| Pitch (A) | 0.5 inch |
|---|---|
| Pitch (A) | 12.7mm |
| Inside Width min (B) | 7.75mm |
| Roller Diameter max (C) | 8.51mm |
| Plate Height max (D) | 11.7mm |
| Plate Width Inner max (E) | 1.55mm |
| Plate Width Outer max (F) | 1.55mm |
| Pin Diameter max (G) | 4.45mm |
| Pin Length max (H1) | 16.5mm |
| Connecting link extension max (J) | 2mm |
| ISO606 Tensile strength min | 17800 N |
| Weight | 0.7 kg/m |
