UC310 Heavy Duty Metric Bearing Insert With 50mm Bore 110mm Outside Dia
UC310 Heavy Duty Metric Bearing Insert With 50mm Bore 110mm Outside Dia
UC310 Heavy Duty Metric Bearing Insert With 50mm Bore 110mm Outside Dia
UC310 Heavy Duty Metric Bearing Insert With 50mm Bore 110mm Outside Dia

SKU: UC.310

UC310 Heavy Duty Metric Bearing Insert With 50mm Bore 110mm Outside Dia

CHF 38.00 ex VAT
CHF 38.00
ex VAT
In stock

Quantity Price Breaks

10+ CHF 33.82
19+ CHF 31.92
29+ CHF 31.54
39+ CHF 31.16
49+ CHF 30.78
74+ CHF 30.40
99+ CHF 28.50
199+ CHF 28.12
249+ CHF 27.74
499+ CHF 27.36
999+ CHF 26.60
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
UC310 Heavy Duty Metric Bearing Insert With 50mm Bore 110mm Outside Dia
UC310 Heavy Duty Metric Bearing Insert With 50mm Bore 110mm Outside Dia
SKU: UC.310

UC310 Heavy Duty Metric Bearing Insert With 50mm Bore 110mm Outside Dia

CHF 38.00 ex VAT
CHF 38.00
ex VAT

Description

UC300 Series Bearing Insert: Bearing insert with 2 grub screws to allow tightening against the shaft once fitted. These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required.
Benefits: Cost effective replacement insert, re-lubricatable, grub screw fixing

Technical

d = 50mm
D = 110mm
Bi = 61mm
Be = 32mm
n = 22mm
m = 39mm
G = 12mm
Grub screw = M12x1.5
Weight = 1.69 kg
Dynamic load = 4850 kgf
Static load = 3640 kgf
