UC305 Heavy Duty Metric Bearing Insert With 25mm Bore 62mm Outside Dia
UC305 Heavy Duty Metric Bearing Insert With 25mm Bore 62mm Outside Dia
UC305 Heavy Duty Metric Bearing Insert With 25mm Bore 62mm Outside Dia
UC305 Heavy Duty Metric Bearing Insert With 25mm Bore 62mm Outside Dia

SKU: UC.305

UC305 Heavy Duty Metric Bearing Insert With 25mm Bore 62mm Outside Dia

CHF 17.00 ex VAT
CHF 17.00
ex VAT
In stock

Quantity Price Breaks

10+ CHF 15.13
19+ CHF 14.28
29+ CHF 14.11
39+ CHF 13.94
49+ CHF 13.77
74+ CHF 13.60
99+ CHF 12.75
199+ CHF 12.58
249+ CHF 12.41
499+ CHF 12.24
999+ CHF 11.90
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
UC305 Heavy Duty Metric Bearing Insert With 25mm Bore 62mm Outside Dia
UC305 Heavy Duty Metric Bearing Insert With 25mm Bore 62mm Outside Dia
SKU: UC.305

UC305 Heavy Duty Metric Bearing Insert With 25mm Bore 62mm Outside Dia

CHF 17.00 ex VAT
CHF 17.00
ex VAT

Description

UC300 Series Bearing Insert: Bearing insert with 2 grub screws to allow tightening against the shaft once fitted. These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required.
Benefits: Cost effective replacement insert, re-lubricatable, grub screw fixing

Technical

d = 25mm
D = 62mm
Bi = 38mm
Be = 22mm
n = 15mm
m = 23mm
G = 6mm
Grub screw = M6x1.0
Weight = 0.45 kg
Dynamic load = 1760 kgf
Static load = 1160 kgf
