SKU: UC.212-36
UC212-36 Imperial Bearing Insert with 2-1/4 inch Bore 110mm Outside Dia
- Regular price
- CHF 41.00 ex VAT
- Sale price
- CHF 41.00
- Regular price
-
In stock
Quantity Price Breaks
10+
CHF 36.49
19+
CHF 34.44
29+
CHF 34.03
39+
CHF 33.62
49+
CHF 33.21
74+
CHF 32.80
99+
CHF 30.75
199+
CHF 30.34
249+
CHF 29.93
499+
CHF 29.52
999+
CHF 28.70
SKU:
UC.212-36
UC212-36 Imperial Bearing Insert with 2-1/4 inch Bore 110mm Outside Dia
- Regular price
- CHF 41.00 ex VAT
- Sale price
- CHF 41.00
- Regular price
-
Description
|
UC or 10 -- G Series: Normal duty bearing insert with 2 grub screws to allow tightening against the shaft once fitted.
These inserts are ideal replacements for housed types which can easily be removed from the housings when replacement is required |
Technical
| d | = | 2-1/4 inch |
| D | = | 110mm |
| Bi | = | 65.1mm |
| Be | = | 27mm |
| n | = | 25.4mm |
| m | = | 39.7mm |
| G | = | 10mm |
| Grub screw | = | 3/8" |
| -24 UNF | = | Weight |
| 1.67 kg | = | Dynamic load |
| 4100 kgf | = | Static load |
| 3150 kgf | = | N/A |
