SKU: SSUCF.209
SSUCF209 Metric Four Bolt Square Stainless Steel Flange Housing with 45mm Bore Stainless Insert
- Regular price
- CHF 163.00 ex VAT
- Sale price
- CHF 163.00
- Regular price
-
In stock
Quantity Price Breaks
10+
CHF 145.07
19+
CHF 136.92
29+
CHF 135.29
39+
CHF 133.66
49+
CHF 132.03
74+
CHF 130.40
99+
CHF 122.25
199+
CHF 120.62
249+
CHF 118.99
499+
CHF 117.36
999+
CHF 114.10
SKU:
SSUCF.209
SSUCF209 Metric Four Bolt Square Stainless Steel Flange Housing with 45mm Bore Stainless Insert
- Regular price
- CHF 163.00 ex VAT
- Sale price
- CHF 163.00
- Regular price
-
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 45mm |
| a | = | 137mm |
| e | = | 105mm |
| i | = | 22mm |
| g | = | 18mm |
| L | = | 38mm |
| S | = | 16mm |
| Z | = | 52.2mm |
| Bi | = | 49.2mm |
| n | = | 19mm |
| Bolt | = | 14mm |
| Weight | = | 2.3 kg |
| Dynamic load | = | 2560 kgf |
| Static load | = | 1810 kgf |
