SKU: SSUCF.204
SSUCF204 Metric Four Bolt Square Stainless Steel Flange Housing with 20mm Bore Stainless Insert
- Regular price
- CHF 55.00 ex VAT
- Sale price
- CHF 55.00
- Regular price
-
In stock
Quantity Price Breaks
10+
CHF 48.95
19+
CHF 46.20
29+
CHF 45.65
39+
CHF 45.10
49+
CHF 44.55
74+
CHF 44.00
99+
CHF 41.25
199+
CHF 40.70
249+
CHF 40.15
499+
CHF 39.60
999+
CHF 38.50
SKU:
SSUCF.204
SSUCF204 Metric Four Bolt Square Stainless Steel Flange Housing with 20mm Bore Stainless Insert
- Regular price
- CHF 55.00 ex VAT
- Sale price
- CHF 55.00
- Regular price
-
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 20mm |
| a | = | 86mm |
| e | = | 64mm |
| i | = | 15mm |
| g | = | 12mm |
| L | = | 25.6mm |
| S | = | 12mm |
| Z | = | 33.3mm |
| Bi | = | 31mm |
| n | = | 12.7mm |
| Bolt | = | 10mm |
| Weight | = | 0.63 kg |
| Dynamic load | = | 1000 kgf |
| Static load | = | 630 kgf |
