SKU: PP60-MXL-025MI
PP60-MXL-025MI - 0.08 inch Pitch 60 Tooth Pilot Bore Polycarbonate (Glass Filled) Timing Pulley with Brass Insert
- Regular price
- CHF 23.00 ex VAT
- Sale price
- CHF 23.00
- Regular price
-
Not in stock
Quantity Price Breaks
3
CHF 20.47
5
CHF 19.32
9
CHF 19.09
19
CHF 18.86
49
CHF 18.63
74
CHF 18.40
99
CHF 17.25
199
CHF 17.02
249
CHF 16.79
499
CHF 16.56
999
CHF 16.10
SKU:
PP60-MXL-025MI
PP60-MXL-025MI - 0.08 inch Pitch 60 Tooth Pilot Bore Polycarbonate (Glass Filled) Timing Pulley with Brass Insert
- Regular price
- CHF 23.00 ex VAT
- Sale price
- CHF 23.00
- Regular price
-
Description
Imperial Pilot Bore Timing Pulley: Imperial timing pulleys are available in both taper and pilot bore. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and number of teeth along with standard widths.
Technical
| No.teeth | = | 60 |
| Dp | = | 38.81mm |
| De | = | 38.3mm |
| Df | = | 43mm |
| Dm | = | 17mm |
| Fw | = | 8mm |
| L | = | 17.5mm |
| Bore (d) | = | 6mm |
| Gs | = | 1 x M3 |
| Material | = | Polycarbonate (Glass Filled) |
| Bore | = | Pilot Bored |
| Belt Width | = | 6.35mm = 0.25 (1/4) inch |
| Pitch | = | 2.03mm = 0.08 inch |
| Pw | = | 11mm |
| Insert | = | Brass |
| K | = | 3inch |
