SKU: PCJ50-TV-FA125.5-INA
INA PCJ50-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 50mm Bore
- Regular price
- CHF 117.00 ex VAT
- Sale price
- CHF 117.00
- Regular price
-
In stock
Quantity Price Breaks
10+
CHF 104.13
19+
CHF 98.28
29+
CHF 97.11
39+
CHF 95.94
49+
CHF 94.77
74+
CHF 93.60
99+
CHF 87.75
199+
CHF 86.58
249+
CHF 85.41
499+
CHF 84.24
999+
CHF 81.90
SKU:
PCJ50-TV-FA125.5-INA
INA PCJ50-TV-FA125.5 Four Bolt Plastic Square Housing with Eccentric Collar Insert 50mm Bore
- Regular price
- CHF 117.00 ex VAT
- Sale price
- CHF 117.00
- Regular price
-
Description
|
INA 4 Bolt Square Housing Units: Supplied with a fully sealed bearing insert fitted in the housing with an eccentric locking collar. This square plastic housing has through holes for location purposes. Due to the spherical outside surface of the bearing outer ring and the concave housing bore, the unit can compensate for static angular misalignment of the shaft of up to 5 degrees if relubrication is not carried out and 2.5 degrees if relubrication is carried out. The bearing insert has a Corrotect® coating which makes it suitable for use if moisture, contaminated water, salt spray mist, weakly alkaline or weakly acidic cleaning agents are present. Benefits: Re-lubricatable, eccentric collar, corrosion-resistant, tolerates misalignment of the shaft. |
