SKU: NTA4052-TRA4052
NTA4052 Needle Roller Cage Thrust Assembly with 2 TRA4052 Washers 2.5x3.25x0.1406 inch
- Regular price
- CHF 20.00 ex VAT
- Sale price
- CHF 20.00
- Regular price
-
Not in stock
Quantity Price Breaks
10
CHF 17.80
19
CHF 16.80
29
CHF 16.60
39
CHF 16.40
49
CHF 16.20
74
CHF 16.00
99
CHF 15.00
199
CHF 14.80
249
CHF 14.60
499
CHF 14.40
999
CHF 14.00
SKU:
NTA4052-TRA4052
NTA4052 Needle Roller Cage Thrust Assembly with 2 TRA4052 Washers 2.5x3.25x0.1406 inch
- Regular price
- CHF 20.00 ex VAT
- Sale price
- CHF 20.00
- Regular price
-
Description
|
NTA Imperial Series Needle Thrust Bearings Complete: Needle roller cage thrust assemblies complete with 2 TRA series washers are a low profile high load thrust bearing assembly, they are made up of a uniform cage which reliably guides a large quantity of needle rollers, the rollers are slightly relieved towards their outer edge to enable uniform load distribution and prevents any edge damage occurence. Benefits: Cost effective thrust solution, wide range, low profile, high load bearing. |
Technical
| d | = | 2.5 inch |
| D | = | 3.25 inch |
| Eb | = | 0.0806 inch |
| Dw | = | 2.59 inch |
| dw | = | 3.07 inch |
| Dynamic load | = | 25.53 kN |
| Static load | = | 152.13 kN |
| Limiting speed | = | 5100 rpm |
| Weight | = | 0.018614 kg |
| Washer | = | Dimensions |
| d | = | 2.500 inch |
| d1 | = | 3.25 inch |
| h min | = | 0.03 inch |
| h max | = | 0.032 inch |
| Pilot min | = | 2.497 inch |
| Pilot max | = | 2.500 inch |
| Dia to clear washer | = | 3.281 inch |
| Weight | = | 0.029 lbs |
