SKU: NAO30x47x16-EU
NAO30x47x16 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
- Regular price
- CHF 23.00 ex VAT
- Sale price
- CHF 23.00
- Regular price
-
In stock
Quantity Price Breaks
10
CHF 20.47
19
CHF 19.32
29
CHF 19.09
39
CHF 18.86
49
CHF 18.63
74
CHF 18.40
99
CHF 17.25
199
CHF 17.02
249
CHF 16.79
499
CHF 16.56
999
CHF 16.10
SKU:
NAO30x47x16-EU
NAO30x47x16 Budget Needle Roller Bearing Without Flanges and With Shaft Sleeve
- Regular price
- CHF 23.00 ex VAT
- Sale price
- CHF 23.00
- Regular price
-
Description
|
Budget Flange-less Needle Roller: The flange-less design permits separation of the supplied inner ring and the outer bearing to facilitate ease of mounting. Benefits: Separable, ease of mounting. |
Technical
| d | = | 30mm |
| D | = | 47mm |
| B | = | 16mm |
| Dynamic load C | = | 23300 N |
| Static load Co | = | 37500 N |
| Fatigue load limit Pu | = | 4500 N |
| Speed in grease | = | 7500 rpm |
| Speed in oil | = | 11000 rpm |
| E | = | 42mm |
| F | = | 35mm |
| r1r2 min | = | 0.3mm |
| S (axial disp) | = | 0.8mm |
| da | = | 41.4mm |
| db | = | 34.5mm |
| Da | = | 42.5mm |
| Db | = | 35.6mm |
| ra max | = | 0.3mm |
| Weight | = | 110 g |
