P80-8M-30 - 8mm Pitch 80 Tooth Flangeless HTD Type Cast Iron Pilot Bore Timing Pulley for 30mm Wide Belts

SKU: HP80-8M-30

P80-8M-30 - 8mm Pitch 80 Tooth Flangeless HTD Type Cast Iron Pilot Bore Timing Pulley for 30mm Wide Belts

CHF 53.00 ex VAT
CHF 53.00
ex VAT
Equivalent to: 808M30
Not in stock

Quantity Price Breaks

3 CHF 47.17
5 CHF 44.52
9 CHF 43.99
19 CHF 43.46
49 CHF 42.93
74 CHF 42.40
99 CHF 39.75
199 CHF 39.22
249 CHF 38.69
499 CHF 38.16
999 CHF 37.10
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
P80-8M-30 - 8mm Pitch 80 Tooth Flangeless HTD Type Cast Iron Pilot Bore Timing Pulley for 30mm Wide Belts
SKU: HP80-8M-30

P80-8M-30 - 8mm Pitch 80 Tooth Flangeless HTD Type Cast Iron Pilot Bore Timing Pulley for 30mm Wide Belts

CHF 53.00 ex VAT
CHF 53.00
ex VAT

Description

HTD Pilot Bore Timing Pulley: High Torque Drive (HTD) timing pulleys are available in both taper and pilot bore. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and number of teeth along with standard widths.

Technical

d Pilot Bore (Nominal) = 15mm
Pitch = 8mm
Belt Width = 30mm
Dp = 203.72mm
De = 202.35mm
Dm = 100mm
F = 38mm
L = 48mm
Number of Teeth = 80
Material = Cast Iron
Type = 3 Pilot Bore
