P56-14M-170F - 14mm Pitch 56 Tooth Flanged HTD Type Steel Pilot Bore Timing Pulley for 170mm Wide Belts

SKU: HP56-14M-170F

P56-14M-170F - 14mm Pitch 56 Tooth Flanged HTD Type Steel Pilot Bore Timing Pulley for 170mm Wide Belts

CHF 400.00 ex VAT
CHF 400.00
ex VAT
Equivalent to: 5614M170F
Not in stock

Quantity Price Breaks

3 CHF 356.00
5 CHF 336.00
9 CHF 332.00
19 CHF 328.00
49 CHF 324.00
74 CHF 320.00
99 CHF 300.00
199 CHF 296.00
249 CHF 292.00
499 CHF 288.00
999 CHF 280.00
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
P56-14M-170F - 14mm Pitch 56 Tooth Flanged HTD Type Steel Pilot Bore Timing Pulley for 170mm Wide Belts
SKU: HP56-14M-170F

P56-14M-170F - 14mm Pitch 56 Tooth Flanged HTD Type Steel Pilot Bore Timing Pulley for 170mm Wide Belts

CHF 400.00 ex VAT
CHF 400.00
ex VAT

Description

HTD Pilot Bore Timing Pulley: High Torque Drive (HTD) timing pulleys are available in both taper and pilot bore. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and number of teeth along with standard widths.

Technical

--- = Pulley Dimensions
Pitch = 14mm
Number of Teeth = 56
Type = 1F Pilot Bore
Dp = 249.55mm
De = 246.76mm
Df = 256mm
Dm = 160mm
F = 187mm
L = 202mm
Pilot Bore - nominal = 32mm
Weight = 45kg
