SKU: HGZ70-JCS
JCS HGZ70 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 50-70mm Band Width 13mm
- Regular price
- CHF 2.00 ex VAT
- Sale price
- CHF 2.00
- Regular price
-
In stock
Quantity Price Breaks
5+
CHF 1.40
10+
CHF 1.20
20+
CHF 1.10
50+
CHF 1.00
100+
CHF 0.80
500+
CHF 0.70
1000+
CHF 0.60
SKU:
HGZ70-JCS
JCS HGZ70 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 50-70mm Band Width 13mm
- Regular price
- CHF 2.00 ex VAT
- Sale price
- CHF 2.00
- Regular price
-
Description
Zinc Plated Steel Hi-Grip Worm Drive Hose Clips: Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse. They are manufactured to exceed BS5315, which has the highest requirements of any of the international standards and tests sealing ability, clamping force and torque.
Technical
| BS No. | = | 70 |
| Adjustment Range (mm) | = | 50-70mm |
| Adjustment Range (inch) | = | 2 - 2-3/4 inch |
| A | = | 13mm |
| B | = | 20mm |
| C | = | 12mm |
| D | = | 16mm |
| E | = | 13mm |
| F | = | 0.9mm |
| Screw | = | 7mm A/F |
| Recommended Torque Nm | = | 6Nm |
| Recommended Torque lb-in | = | 54lb-in |
