SKU: 6212-HT-330
6212HT330 High Temp 330C Open Deep Groove Ball Bearing 60x110x22mm Max 65rpm
- Regular price
- CHF 33.00 ex VAT
- Sale price
- CHF 33.00
- Regular price
-
ex VAT
Quantity Price Breaks
Description
HT330 Series High Temperature Bearings: Manufactured with a steel cage to further enhance the bearings performance, supplied un-shielded are designed for high temperatures up to + 330 degrees Celsius and down to - 30 degrees Celsius. At temperatures over + 200 dry lubrication pertains. Designed for low speeds at temperature without maintenance. Internal clearance is increased to compensate expansions and all have a BLACK PHOSPHATE COATING
Benefits: High temperature resilience, low maintenance, can be re-lubricated
Technical
| Inside diameter d | = | 60mm |
| Outside diameter D | = | 110mm |
| Width W | = | 22mm |
| Static load max | = | 20.81 kN |
| Max operating temperature | = | 330 deg Celcius |
| Maximum speed | = | 65 rpm |
| Weight | = | 780 g |
