Codex 61900ZZ Metal Shielded Thin Section Deep Groove Ball Bearing 10x22x6mm

SKU: 61900-ZZ-CDX

Codex 61900ZZ Metal Shielded Thin Section Deep Groove Ball Bearing 10x22x6mm

CHF 8.00 ex VAT
CHF 8.00
ex VAT
Equivalent to: 61900ZZ 619002Z 619002ZR 61900ZZE 61900FF 61900DD 61900DDC 61900KDDC EL10ZZ EL102Z
In stock

Quantity Price Breaks

4 CHF 7.12
10 CHF 6.72
20 CHF 6.64
30 CHF 6.56
50 CHF 6.48
75 CHF 6.40
100 CHF 6.00
200 CHF 5.92
250 CHF 5.84
500 CHF 5.76
1000 CHF 5.60
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
Codex 61900ZZ Metal Shielded Thin Section Deep Groove Ball Bearing 10x22x6mm
SKU: 61900-ZZ-CDX

Codex 61900ZZ Metal Shielded Thin Section Deep Groove Ball Bearing 10x22x6mm

CHF 8.00 ex VAT
CHF 8.00
ex VAT

Description

Metal Shielded Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing.
Shields can be removed for applications that only require 1 shield
Benefits: Provides light mechanical protection, limits moisture and dirt ingress, lubricated for life, cost effective solution

Technical

d = 10mm
D = 22mm
B = 6mm
Dynamic Load = 2.08 kN
Static Load = 0.85 kN
Fatigue Load Limit Pu = 0.036
Reference Speed = 75000 rpm
Limiting Speed = 36000 rpm
Weight = 0.01kg
d2 = 12mm
D2 = 19mm
r1r2 min = 0.3mm
da min = 12mm
da max = 12mm
Da max = 20mm
ra max = 0.3
Calc factor kr = 0.02
Calc factor Cor f0 = 9.3
