FAG 4303BTV Double Row Deep Groove Ball Bearing 17x47x19mm

SKU: 4303.B.TV

FAG 4303BTV Double Row Deep Groove Ball Bearing 17x47x19mm

CHF 37.00 ex VAT
CHF 37.00
ex VAT
In stock

Quantity Price Breaks

10 CHF 32.93
19 CHF 31.08
29 CHF 30.71
39 CHF 30.34
49 CHF 29.97
74 CHF 29.60
99 CHF 27.75
199 CHF 27.38
249 CHF 27.01
499 CHF 26.64
999 CHF 25.90
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
FAG 4303BTV Double Row Deep Groove Ball Bearing 17x47x19mm
SKU: 4303.B.TV

FAG 4303BTV Double Row Deep Groove Ball Bearing 17x47x19mm

CHF 37.00 ex VAT
CHF 37.00
ex VAT

Description

Double Row Deep Groove Ball Bearings: Similar in design to single row deep groove ball bearings, they have two parallel deep grooves and high conformity between the balls and the raceways. They are able to carry axial loads in both directions in addition to radial loads. These are particularly suited to applications where a single row ball bearing's load bearing capacity would be insufficient. Made with the same bore and outside diameters as the single row series they are a little bit wider but offer far greater load bearing ability
Benefits: Higher axial and radial load than single row, same bore and diameter as single row equivalent size

Technical

Bore = 17mm
Outside Diameter = 47mm
Width = 19mm
